Build a virtual S2D cluster with Windows Server 2019 build 17744

Windows Server 2016 and 2019 Storage Sapces Direct (S2D) allows building HA storage systems using storage nodes with local storage, such as SATA or SSD disks.

In this blogpost, I’ll deploy a two node S2D cluster based on Windows Server 2019 build 17744. The main machine is a HP ProBook 450 G5 with Windows 10, 16 GB memory, 512 GB SSD disk, and Hyper-V enabled.

First of all, I’ve deployed the following virtual machines:

  • S2D-W2019-DC01 (Domain Controller, DNS, Group Policies)
    IP address: 172.16.0.100
  • S2D-W2019-HV01 (Hyper-V host, S2D node)
    IP address: 172.16.0.101 (LAN)
    IP address: 10.10.0.101 (Live Migration)
  • S2D-W2019-HV02 (Hyper-V host, S2D node)
  • IP address: 172.16.0.102 (LAN)
    IP address: 10.10.0.102 (Live Migration)

All the servers are installed with Windows Server 2019 build 17744. The first server I’ve configured is the domain controller. My internal domain is s2dlab.local.

For both S2D nodes (S2D-W2019-HV01 and S2D-W2019-HV02), you’ve to configure some additional settings, because this servers are virtual. So we’re going to run Hyper-V in Hyper-V and on that Hyper-V host there’re some guest virtual machines (nested virtualization) 😀 Cool stuff!!!


$S2DHOST1 = 'S2D-W2019-HV01'
$S2DHOST2 = 'S2D-W2019-HV02'

# List all virtual machines
Get-VM

# Enable nested virtualization on virtual machines
Set-VMProcessor -VMName $S2DHOST1 -ExposeVirtualizationExtensions $true
Set-VMProcessor -VMName $S2DHOST2 -ExposeVirtualizationExtensions $true

Next, you’ve to Configure the following settings within the VM configuration:

  • Disable dynamic memory;
  • Set the number of virtual processors to 2 or 4;
  • Turn on MAC address spoofing on your network interface(s);



Now the domain controller is up and running and both S2D nodes are installed and configured with Windows Server 2019, it’s time to add some storage. Both servers have 3 x 50 GB virtual disks attached! Note!! this is only for testing and demo!!

So we’ve 300 GB storage available for our S2D cluster. After this is done, you can install the following roles and features within Windows Server:

  • (Role) File and Storage Services;
  • (Role) Hyper-V;
  • (Feature) Failover Clustering;



Now all the components are ready to build the cluster. It’s recommended to run the cluster validation before building your cluster! The name of my cluster is ‘S2D-CL01’ with IP address 172.16.0.200/16. Note!! Uncheck the option ‘Add all eligible storage to the cluster’!!

The cluster is up and running. As you can see within your Active Directory and DNS configuration, there’re three computer objects (two cluster nodes and one Failover Cluster object).



The last step before enabling ‘S2D’ on our cluster is checking the disk configuration.


# List all available disks within the cluster nodes
Get-PhysicalDisk

# Enable Storage Spaces Direct on the cluster
Enable-ClusterS2D

# List all Storage Pools within the S2D cluster
Get-Storagepool S2D*



Now our cluster is Storage Spaces Direct (S2D) enabled. The last step is to create a virtual disk within our Storage Pool and add it as a Cluster Shared Volume (CSV) to the cluster, wo we can store workloads on it! Bacause we’ve a two node cluster, the only Resiliency type is Two-Way Mirror.



Wrap Up:

In this blogpost we’ve builded a two nodes virtual Storage Spaces Direct cluster in Hyper-V (Windows 10). The S2D nodes are running Windows Server 2019. It’s really a nice opportunity to run this configuration virtual on your laptop or desktop, while nested virtualization is supported and it works great!!

In the next blogpost I’ll show you to install and configure a virtual machine within our S2D cluster. Also performing some live migrations to show the high availability and resiliency of our setup!

WIN – SysAdmin Day Contest – WIN

Feeling lucky? #WIN one of 101 fantastic prizes with #Altaro VM Backup, including a PlayStation 4 Pro, Xbox One X, Amazon eGift Cards and more! Enter our #SysAdminDay Contest today and don’t forget to share this post with your friends!

Experts Live NL 2018 Intro Movie

Last Tuesday, it was a great day again! Experts Live 2018 NL. The biggest community event in the Netherlands. Great sessions, great speakers, very high level of content, great demos and off course as always a great intro movie!! 🙂 Many thanks to the organization of Experts Live! See you next year!!

http://www.expertslive.nl

Download Microsoft Ignite 2017 session content

This script can download all the Microsoft Ignite slidedecks and videos that are available from the Ignite portal. Very useful if you want to watch all the movies and sessions once again!! In this example I’ll download only the sessions with the keyword “IaaS”. But you can also download all the content, or just by title, speaker, etc.

Download the script from Microsoft Gallery here.


\Get-IgniteSession.ps1 -DownloadFolder C:\Ignite2017 -Keyword "IaaS"

Happy New Year!!

With a few days to go, 2017 is there!! 2016 was a really great year. The number of visitors on my blog is growing every day, so hopefully this will continue in 2017.

I want to thank all the sponsors for the support on my blog!! Also special thanks to all the visitors on my blog!

I wish all of you a happy new year and a great 2017!!!

Happy-New-Year-2017

How to: Resize hard disk in Azure Resource Manager (ARM)

Resizing a virtual hard disk in Azure Resource Manager is really easy to do through the Azure Managent Portal. In a few clicks you can extend the virtual hard disk size. Note that the VM should be turned off!! So you need to plan a maintenance window!!
You can also extend the virtual hard disk with PowerShell. In this example I’ve extended the data disk from 25 to 30 GB.


# Specify the VM
$VM = Get-AzureRmVM -ResourceGroupName MSS-DEMO -VMName MSS-DEMO-DC01
# Set the new size of the data disk
Set-AzureRmVMDataDisk -VM $VM -Name MSS-DEMO-DC01-20160801-100246 -DiskSizeInGB 30
# View the new size of the data disk(s)
$VM.StorageProfile.DataDisks
# Update the configuration in Azure
Update-AzureRmVM -VM $VM -ResourceGroupName MSS-DEMO

2016-08-01_10h31_33    2016-08-01_09h45_27    2016-08-01_10h11_55

2016-08-01_10h12_18    2016-08-01_10h25_33    2016-08-01_10h25_49

2016-08-01_10h31_15     2016-08-01_10h32_11    2016-08-01_10h33_23

1.) Login to the Azure Management Portal
2.) Check the current size of the data disk. In my example 25 GB
3.) Start PowerShell and login to your Azure subscription
4.) Change the data disk to the new value
5.) Update the configuration to Azure
6.) Check the new size of the data disk with PowerShell or within the Azure Management Portal.
In my example the new size is 30 GB.



How to: Initialize, format and label disks during OSD Task Sequence in SCCM 2012 R2

During a task seuence in Microsoft SCCM 2012 R2, the operating system and applications are installed on the C: drive in most situations. But in some deployments, you definitely want to create more disks. For example, you want to create a D: and E: partition for storing some other data. Maybe for Microsoft SQL or Exchange installation, databases, logfiles or just some other data.

The following script will do all these steps for you during the task sequence. The script initialize, format, partition and label the disks for you….fully automated! 🙂

## Set CD-ROM from E: to X:
Set-WmiInstance -InputObject ( Get-WmiObject -Class Win32_volume -Filter "DriveLetter = 'E:'" ) -Arguments @{DriveLetter='X:'}

$disks = Get-Disk | measure
If($disks.Count -eq 2)
{
## Initialize all new disks
Initialize-Disk 1
## Format and rename disks
Get-Disk | where {$_.Number -eq "1"} | New-Partition -UseMaximumSize | Format-Volume -FileSystem NTFS -NewFileSystemLabel Data -Confirm:$false
## Set drive letters (D: - Data, E: - Backup)
Get-Disk | where {$_.Number -eq "1"} | Get-Partition | where {$_.PartitionNumber -eq 2} | Set-Partition -NewDriveLetter D
}
elseif($disks.Count -eq 3)
{
## Initialize all new disks
Initialize-Disk 1
Initialize-Disk 2
## Format and rename disks
Get-Disk | where {$_.Number -eq "1"} | New-Partition -UseMaximumSize | Format-Volume -FileSystem NTFS -NewFileSystemLabel Data -Confirm:$false
Get-Disk | where {$_.Number -eq "2"} | New-Partition -UseMaximumSize | Format-Volume -FileSystem NTFS -NewFileSystemLabel Backup -Confirm:$false
## Set drive letters (D: - Data, E: - Backup)
Get-Disk | where {$_.Number -eq "1"} | Get-Partition | where {$_.PartitionNumber -eq 2} | Set-Partition -NewDriveLetter D
Get-Disk | where {$_.Number -eq "2"} | Get-Partition | where {$_.PartitionNumber -eq 2} | Set-Partition -NewDriveLetter E
}
else
{
exit
}
exit

The script first checks how many disks are attached to the server.
If there is only one disk attached, you’ll have only a C: drive available after the deployment.
If there are 2 disks attached, you’ll have a C: and D: drive avalailable after the deployment.
If there are 3 disks attached, you’ll have a C:, D: and E: drive available after the deployment.

The CD-ROM drive will alse changed from E: to X:.
